The empty ampoules are fed through an inclined charging hopper via continuously rotating feeding wheel. The ampoule is transferred positively from charging hopper to an ampoule tack and two centering racks which carry One ampoule to filling system to fill set volume in the ampoules. Then onwards ampoule moves to sealing station consisting of the ampoule revolving station, sealing burners as well as draw-off jaws to seal the filled ampoule neatly. Finally the filled and sealed ampoules are collected in the horizontal collecting chute.
AUTOMATIC SINGLE HEAD AMPOULE FILLING & SEALING MACHINE
MODEL: AAFS-30
Technical Specifications:
| Machine Model | AAFS-30 | |
| No. of Heads | One | |
| Output/Minute | 10-25 Ampoule/Minute depending on Ampoule size | |
| Working direction | Left to Right | |
| Electric Characteristic | 0.5 HP/230V/1440 RPM/Single Phase/50 Hz | |
| Other utilities | Oxygen + Nitrogen (Customer’s scope) | |
| Power Supply | Single Phase/3 Phase, 4 Wire | |
| Input Specifications | Ampoule size: | Min. 9.5mm to Maxi. 23mm (1ml to 25ml) |
| Overall dimensions | 765mmL x 890mm W x 965mm H | |
| Net Weight | 150 kgs | |
| Gross Weight | 300 kgs. | |
(The above specifications may change with the inclusion of latest technologies)
