AUTOMATIC 6 x 6 HEAD MOTION TYPE BOTTLE LIQUID FILLING & PRESS ON CAPPING MACHINE (MONOBLOCK)

MODEL: MOTION MBFPC 6x6

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Cap Pressing Head for perfect cap pressing on filled and capped bottled. Then after the bottles moves on conveyor via outfeed starwheel for next operation.

Technical Specifications:

Machine Model

MOTION MBFPC 6x6

No. of Heads/Syringes

Six

No. of Capping Head

Six

Fill Capacity

50ml to 250ml with the help of change parts

Fill Accuracy

+  1%

Output/Minute

80 to 120 Bottles depending on viscosity & fill volume

Working direction

Left to Right

Electric Characteristic

Main Motor

1 HP/230V/1440 RPM/Single Phase/50 Hz

Conveyor Motor

0.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

20mm to 75mm

Bottle height

25mm to 170mm

Overall dimensions

3450 mm L x 1156 mm W x  2500 mm H

Net Weight

1800 Kgs.

Gross Weight

2100 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 8 x 8 HEAD MOTION TYPE BOTTLE LIQUID FILLING & PRESS ON CAPPING MACHINE (MONOBLOCK)

MODEL: MOTION MBFPC 8x8

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Cap Pressing Head for perfect cap pressing on filled and capped bottled. Then after the bottles moves on conveyor via outfeed starwheel for next operation

Technical Specifications:

Machine Model MOTION MBFPC 8x8
No. of Heads/Syringes Eight
No. of Capping Head Eight
Fill Capacity 50ml to 250ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 80 to 150 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 5 HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 3650 mm L x 1156 mm W x 2500 mm H
Net Weight 1900 kgs.
Gross Weight 2200 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 12 x 12 HEAD MOTION TYPE BOTTLE LIQUID FILLING & SCREW CAPPING MACHINE (MONOBLOCK)

MODEL: MOTION MBFPC 12x12

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Cap Pressing Head for perfect cap pressing on filled and capped bottled. Then after the bottles moves on conveyor via outfeed starwheel for next operation

Technical Specifications:

Machine Model MOTION MBFPC 12x12
No. of Heads/Syringes Twelve
No. of Capping Head Twelve
Fill Capacity 50ml to 250ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 80 to 250 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 5 HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 5500 mm L x 1260 mm W x 25000 mm H
Net Weight 2300 kgs.
Gross Weight 2650 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC 16 x 16 HEAD MOTION TYPE BOTTLE LIQUID FILLING & PRESS ON CAPPING MACHINE (MONOBLOCK)

MODEL: MOTION MBFPC 16x16

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operationAfter filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Cap Pressing Head for perfect cap pressing on filled and capped bottled. Then after the bottles moves on conveyor via outfeed starwheel for next operation

Technical Specifications:

Machine Model MOTION MBFPC 16x16
No. of Heads/Syringes Sixteen
No. of Capping Head Sixteen
Fill Capacity 50ml to 250ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 80 to 280 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 6 HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 7350 mm L x 1506 mm W x  2500 mm H
Net Weight 2700 kgs.
Gross Weight 3100 kgs.

(The above specifications may change with the inclusion of latest technologies)
