Turn Tables

  • ATT-24
  • ATT-30
  • ATT-36
  • ATT-48

24” DIA. TURN TABLE

MODEL: ATT-24

Turn table made of aluminium disc. Cladded with SS and is generally used to feed the vials/bottles to subsequent machine or to collect vials/bottles from the previous machine.

Technical Specifications:

Machine Model ATT-24
Turn table dia. 24”
Electric Characteristic 0.5HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Overall dimensions 637mm L x 637mm W x 1200mm H
Net Weight 65 kgs.
Gross Weight 120 kgs.

(The above specifications may change with the inclusion of latest technologies)

30” DIA. TURN TABLE

MODEL: ATT-30

Turn table made of aluminium disc. Cladded with SS and is generally used to feed the vials/bottles to subsequent machine or to collect vials/bottles from the previous machine.

Technical Specifications:

Machine Model

ATT-30

Turn table dia.

30”

Electric Characteristic

0.5HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Overall dimensions

800mm L x 800mm W x 1200mm H

Net Weight

80 Kgs.

Gross Weight

140 Kgs.

(The above specifications may change with the inclusion of latest technologies)

36” DIA. TURN TABLE

MODEL: ATT-36

Turn table made of aluminium disc. Cladded with SS and is generally used to feed the vials/bottles to subsequent machine or to collect vials/bottles from the previous machine.

Technical Specifications:

Machine Model

ATT-36

Turn table dia.

36”

Electric Characteristic

0.5HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Overall dimensions

940mm L  x 940mm W x 1200mm H

Net Weight

90 Kgs.

Gross Weight

150 Kgs.

(The above specifications may change with the inclusion of latest technologies)

48” DIA. TURN TABLE

MODEL: ATT-48

Turn table made of aluminium disc. Cladded with SS and is generally used to feed the vials/bottles to subsequent machine or to collect vials/bottles from the previous machine.

Technical Specifications:

Machine Model

ATT-48

Turn table dia.

48”

Electric Characteristic

0.5HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Overall dimensions

1250mm L x 1250mm W x 1200mm H

Net Weight

130 Kgs.

Gross Weight

200 Kgs.

(The above specifications may change with the inclusion of latest technologies)
