The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation. After filling, the filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.
AUTOMATIC 6 x 6 HEAD MOTION TYPE BOTTLE LIQUID FILLING & SCREW CAPPING MACHINE (MONOBLOCK)
MODEL: MBFSC 6x6
Technical Specifications:
Machine Model |
MOTION MBFSC 6x6 |
|
No. of Heads/Syringes |
Six |
|
No. of Capping Head |
Six |
|
Fill Capacity |
50ml to 250ml with the help of change parts |
|
Fill Accuracy |
+ 1% |
|
Output/Minute |
80 to 120 Bottles depending on viscosity & fill volume |
|
Working direction |
Left to Right |
|
Electric Characteristic |
Main Motor |
1 HP/230V/1440 RPM/Single Phase/50 Hz |
Conveyor Motor |
0.5 HP/230V/1440 RPM/Single Phase/50 Hz |
|
Power Supply |
Single Phase/3 Phase, 4 Wire |
|
Input Specifications |
Bottle dia. |
20mm to 75mm |
Bottle height |
25mm to 170mm |
|
Overall dimensions |
3450 mm L x 1156 mm W x 2500 mm H |
|
Net Weight |
1800 Kgs. |
|
Gross Weight |
2100 Kgs. |
|
(The above specifications may change with the inclusion of latest technologies)
