AUTOMATIC SINGLE HEAD SCREW CAPPING MACHINE

MODEL: ABSC-60

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model

ABSC-60

No. of Heads

One

Output/Minute

25-50 Bottles

Working direction

Left to Right

Electric Characteristic

2 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

22mm to 70mm

Bottle height

50mm to 200mm

Cap dia.

22mm, 25mm, 28mm and 32mm cap

Overall dimensions

1610mm L x 856mm W x 1950mm H

Net Weight

580 kgs

Gross Weight

800 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC FOUR HEAD SCREW CAPPING MACHINE

MODEL: ABSC-80

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model

ABSC-80

No. of Heads

Four

Output/Minute

25-80 Bottles

Working direction

Left to Right

Electric Characteristic

3 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

22mm to 70mm

Bottle height

50mm to 200mm

Cap dia.

22mm, 25mm, 28mm and 32mm cap

Overall dimensions

1800mm  L x 1156mm  W  x 2500 mm H

Net Weight

970 kgs.

Gross Weight

1300 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC SIX HEAD SCREW CAPPING MACHINE

MODEL: ABSC-100

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model ABSC-100
No. of Heads Six
Output/Minute 60-120 Bottles
Working direction Left to Right
Electric Characteristic 3 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      22mm to 70mm
Bottle height 50mm to 200mm
Cap dia. 22mm, 25mm, 28mm and 32mm cap
Overall dimensions 2400mm L x 1156mm W x 250mm H
Net Weight 1100 Kgs.
Gross Weight 1400 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC EIGHT HEAD SCREW CAPPING MACHINE

MODEL: ABSC-150

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model

ABSC-150

No. of Heads

Eight

Output/Minute

80-150 Bottles

Working direction

Left to Right

Electric Characteristic

3 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

22mm to 70mm

Bottle height

50mm to 200mm

Cap dia.

22mm, 25mm, 28mm and 32mm cap

Overall dimensions

2400mm L x 1156mm W x 250mm H

Net Weight

1150 Kgs.

Gross Weight

1450 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC TWELVE HEAD SCREW CAPPING MACHINE

MODEL: ABSC-200

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model

ABSC-200

No. of Heads

Twelve

Output/Minute

80-200 Bottles

Working direction

Left to Right

Electric Characteristic

4 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

22mm to 70mm

Bottle height

50mm to 200mm

Cap dia.

22mm, 25mm, 28mm and 32mm cap

Overall dimensions

3250mm L x 1256mm W x 2500mm H

Net Weight

1550 kgs.

Gross Weight

1900 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC SIXTEEN HEAD SCREW CAPPING MACHINE

MODEL: ABSC-250

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect SCREW Capping.

Technical Specifications:

Machine Model

ABSC-250

No. of Heads

Sixteen

Output/Minute

80-250 Bottles

Working direction

Left to Right

Electric Characteristic

4.5 HP/230V/1440 RPM/Single Phase/50 Hz

Power Supply

Single Phase/3 Phase, 4 Wire

Input Specifications

Bottle dia.

22mm to 70mm

Bottle height

50mm to 200mm

Cap dia.

22mm, 25mm, 28mm and 32mm cap

Overall dimensions

33305mm L x 1506mm W x 2500mm H

Net Weight

1650 kgs.

Gross Weight

2000 kgs.

(The above specifications may change with the inclusion of latest technologies)
