AUTOMATIC SINGLE HEAD ROPP CAPPING MACHINE

MODEL: ABRC-60

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model ABRC-60
No. of Heads One
Output/Minute 25-50 Bottles
Working direction Left to Right
Electric Characteristic 2 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      22mm to 70mm
Bottle height 50mm to 200mm
Cap dia. 22mm, 25mm, 28mm and 32mm cap
Overall dimensions 1610mm L  x 856mm W x 1950mm H
Net Weight 580 kgs
Gross Weight 800 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC FOUR HEAD ROPP CAPPING MACHINE

MODEL: ABRC-80

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model ABRC-80
No. of Heads Four
Output/Minute 25-80 Bottles (depending upon operator skill)
Working direction Left to Right
Electric Characteristic 3 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      22mm to 70mm
Bottle height 50mm to 200mm
Cap dia. 22mm, 25mm, 28mm and 32mm cap
Overall dimensions 1800mm  L x 1156mm  W  x 2500 mm H
Net Weight 970 kgs.
Gross Weight 1300 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC SIX HEAD ROPP CAPPING MACHINE

MODEL: ABRC-100

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model ABRC-100
No. of Heads Six
Output/Minute 60-120 Bottles (depending upon operator skill)
Working direction Left to Right
Electric Characteristic 3 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      22mm to 70mm
Bottle height 50mm to 200mm
Cap dia. 22mm, 25mm, 28mm and 32mm cap
Overall dimensions 2400mm  L  x 1156mm  W x 250mm  H
Net Weight 1100 Kgs.
Gross Weight 1400 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC EIGHT HEAD ROPP CAPPING MACHINE

MODEL: ABRC-150

On-line filled containers are fed and guided on the moving SS/Plastic slat conveyor belt at the required speed of the correct placement below Capping Head. The filled bottle moving in star wheel pick up cap from the cap chute and move under the Capping head for perfect ROPP Capping.

Technical Specifications:

Machine Model ABRC-150
No. of Heads Eight
Output/Minute 80-150 Bottles (depending upon operator skill)
Working direction Left to Right
Electric Characteristic 3 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      22mm to 70mm
Bottle height 50mm to 200mm
Cap dia. 22mm, 25mm, 28mm and 32mm cap
Overall dimensions 2400mm L x 1156mm  W x 250mm H
Net Weight 1150 Kgs.
Gross Weight 1450 Kgs.

(The above specifications may change with the inclusion of latest technologies)
