LINEAR AUTOMATIC SIX HEAD MOTION TYPE BOTTLE LIQUID FILLING MACHINE

MODEL: MOTION-FILL-6

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation.

Technical Specifications:

Model MOTION-FILL-6
No. of Heads/Syringes Six
Fill Capacity 5ml to  250ml (with the help of change parts)
Fill Accuracy +  1%
Output/minute 80 to 120
Working direction Left to Right
Electric characteristic Main motor     2.5 HP, 220V. 1440 RPM, Single Phase, 50 Hz
Conveyor    0.5 HP, 220V. 1440RPM, Single Phase, 50 Hz.
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Container Dia. 20mm to 75mm
  Container Ht. 25mm to 170mm
Overall dimensions 3000 mm L x 904 mm W x 1950 mm H
Net Weight 700 Kgs.
Gross Weight 1000 Kgs.

(The above specifications may change with the inclusion of latest technologies)

LINEAR AUTOMATIC EIGHT HEAD MOTION TYPE BOTTLE LIQUID FILLING MACHINE

MODEL: MOTION-FILL-8

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation.

Technical Specifications:

Model MOTION-FILL-8
No. of Heads/Syringes Eight
Fill Capacity 5ml to  250ml (with the help of change parts)
Fill Accuracy +  1%
Output/minute 80 to 175
Working direction Left to Right
Electric characteristic Main motor     2.5 HP, 220V. 1440 RPM, Single Phase, 50 Hz
Conveyor    0.5 HP, 220V. 1440RPM, Single Phase, 50 Hz.
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Container Dia. 20mm to 75mm
  Container Ht. 25mm to 170mm
Overall dimensions 3000 mm L x 881 mm W x 1950 mm H
Net Weight 800 Kgs.
Gross Weight 1100 kgs.

(The above specifications may change with the inclusion of latest technologies)

LINEAR AUTOMATIC TEN HEAD MOTION TYPE BOTTLE LIQUID FILLING MACHINE

MODEL: MOTION-FILL-10

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation.

Technical Specifications:

Model Motion-Fill-10
No. of Heads/Syringes 10 Nos.
Fill Capacity 5ml to  250ml (with the help of change parts)
Fill Accuracy +  1%
Output/minute 80 to 175
Working direction Left to Right
Electric characteristic Main motor     2 HP, 220V. 1440 RPM, Single Phase, 50 Hz
Conveyor    0.5 HP, 220V. 1440RPM, Single Phase, 50 Hz.
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Container Dia. 20mm to 75mm
  Container Ht. 25mm to 170mm
Overall dimensions 2800 mm L x 950 mm W x 1700 mm H
Net Weight 1000 Kgs.
Gross Weight 1400 kgs.

(The above specifications may change with the inclusion of latest technologies)

LINEAR AUTOMATIC TWELVE HEAD MOTION TYPE BOTTLE LIQUID FILLING MACHINE

MODEL: MOTION-FILL-12

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation.

Technical Specifications:

Model Motion-FILL-12
No. of Heads/Syringes Twelve
Fill Capacity 5ml to  250ml (with the help of change parts)
Fill Accuracy +  1%
Output/minute 80 to 200
Working direction Left to Right
Electric characteristic Main motor     2.5 HP, 220V. 1440 RPM, 3 Phase, 50 Hz
Conveyor    0.5 HP, 220V. 1440RPM, Single Phase, 50 Hz.
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 4050 mm L x  1206 mm W x 1950 mm H
Net Weight 1000 Kgs.
Gross Weight 1350 kgs.

(The above specifications may change with the inclusion of latest technologies)

LINEAR AUTOMATIC SIXTEEN HEAD MOTION TYPE BOTTLE LIQUID FILLING MACHINE

MODEL: MOTION-FILL-16

The incoming dry bottles (sterilized and siliconised) are fed through the in-feed turn table and suitably guided to feed worm. At the same time, synchronized filling nozzle unit moving alongwith the bottles fill the set fill liquid volume into bottle during it movement into feed worm. If required, centering device is provided. On completion of one filling cycle, the filling nozzle unit sliding back for next filling operation.

Technical Specifications:

Model MOTION-FILL-16
No. of Heads/Syringes Sixteen
Fill Capacity 5ml to  250ml (with the help of change parts)
Fill Accuracy +  1%
Output/minute 80 to 200
Working direction Left to Right
Electric characteristic Main motor     2.5 HP, 220V. 1440 RPM, 3 Phase, 50 Hz
Conveyor    0.5 HP, 220V. 1440RPM, Single Phase, 50 Hz.
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 6000 mm L x 1506 mm W x 1950 mm H
Net Weight 1200 kgs.
Gross Weight 1600 kgs.

(The above specifications may change with the inclusion of latest technologies)
