AUTOMATIC FOUR HEAD BOTTLE LIQUID FILLING MACHINE

MODEL: ABLF-80

The dry sterilized and siliconised bottles are fed through the in-feed turn table and Four bottles in raw are held by pneumatic stoppers below the filling nozzles at a time for set fill volume. On completion of filling operation, the filled bottles are released on conveyor for next operation.

Technical Specifications:

Machine Model ABLF-80
No. of Heads/Syringes Four
Fill Capacity 15ml to 500ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 25 to 60 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 1 HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 1600 mm L x 856 mm W x 1950 mm H
Net Weight 450 kgs.
Gross Weight 700 kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC SIX HEAD BOTTLE LIQUID FILLING MACHINE

MODEL: ABLF-100

The dry sterilized and siliconised bottles are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed for the correct placement below filling unit. SixBottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. On completion of filling operation, the filled bottles are released on conveyor for next operation.

Technical Specifications:

Machine Model ABLF-100
No. of Heads/Syringes Six
Fill Capacity 15ml to 500ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 60 to 90 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 1.5 HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 1800 mm L x 904 mm W x 1950 mm H
Net Weight 600 Kgs.
Gross Weight 900 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC EIGHT HEAD BOTTLE LIQUID FILLING MACHINE

MODEL: ABLF-150

The dry sterilized and siliconised bottles are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed for the correct placement below filling unit. Eight Bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. On completion of filling operation, the filled bottles are released on conveyor for next operation.

Technical Specifications:

Machine Model ABLF-150
No. of Heads/Syringes Eight
Fill Capacity 15ml to 500ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 90 to 120 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 2  HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 2400 mm L x  881 mm W x 1950 mm H
Net Weight 700 Kgs.
Gross Weight 1000 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC TEN HEAD BOTTLE LIQUID FILLING MACHINE

MODEL: ABLF-200

The dry sterilized and siliconised bottles are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed for the correct placement below filling unit. Ten Bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. On completion of filling operation, the filled bottles are released on conveyor for next operation.

Technical Specifications:

Machine Model ABLF-200
No. of Heads/Syringes Ten
Fill Capacity 15ml to 500ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 120-180 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 2  HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 3050 mm L x  1006 mm W x 1950 mm H
Net Weight 800 Kgs.
Gross Weight 1100 Kgs.

(The above specifications may change with the inclusion of latest technologies)

AUTOMATIC TWELVE HEAD BOTTLE LIQUID FILLING MACHINE

MODEL: ABLF-250

The dry sterilized and siliconised bottles are fed through the in-feed turn table and suitably guided on the moving SS/Plastic slat conveyor belt at the required speed for the correct placement below filling unit. Ten Bottles in a raw are held by pneumatic stoppers at a time below the filling nozzles. During the stationary position, the set fill volume is delivered into bottles. On completion of filling operation, the filled bottles are released on conveyor for next operation.

Technical Specifications:

Machine Model ABLF-250
No. of Heads/Syringes Twelve
Fill Capacity 15ml to 500ml with the help of change parts
Fill Accuracy +  1%
Output/Minute 150-220 Bottles depending on viscosity & fill volume
Working direction Left to Right
Electric Characteristic Main Motor 2  HP/230V/1440 RPM/Single Phase/50 Hz
Conveyor Motor 0.5 HP/230V/1440 RPM/Single Phase/50 Hz
Power Supply Single Phase/3 Phase, 4 Wire
Input Specifications Bottle dia.      20mm to 75mm
Bottle height 25mm to 170mm
Overall dimensions 3050 mm L x  1006 mm W x 1950 mm H
Net Weight 850 Kgs.
Gross Weight 1150 Kgs.

(The above specifications may change with the inclusion of latest technologies)
